MDE850M - Horizontal Platform Three-Axis XYZ Micropositioner Stage with Micrometers
Horizontal Platform Three-Axis XYZ Micropositioner Stage with Micrometer adjustment
- Stainless steel body
- Small dovetail slides
- Micrometer adjusters
- Wide range of configurations
- Adjustable horizontal platform
- Very smooth backlash-free motion
The MDE850M is a three-axis XYZ micropositioner with micrometer adjustment configured to provide a horizontal platform that can be moved in the XY plane plus vertically along the Z-axis. The MDE850M is a variation on the MDE259M, and is based on the MDE255M dovetail slides.
MDE255M Series Drawing
Click here to download
|Micrometer scale||0.01 mm|
Note: Surface mating with these micropositioners must be truly flat. Unflat surfaces or overtightened screws will cause the slide motion to be jerky and stiff due to distortion. Dovetail slides, unlike miniature ball slides, are unlikely to be permanently damaged by temporary distortion, as the load is supported on a comparatively large area.
